Tech Spec

  • Panel

    Screen Size 55″
    Panel Technology IPS
    Aspect Ratio 16:9
    Native Resolution 1,920 x 1,080 (FHD)
    Brightness (Typ.) 500nit
    Contrast Ratio 1,100:1
    Viewing Angle (H x V) 178 X 178
    Response Time 8ms (G to G)
    Surface Treatment (Haze) 28%
    Operation Hours (Hours / Days) 24/7
    Portrait / Landscape Yes / Yes
  • Mechanical Specification

    Bezel Color Black
    Bezel Width Even bezel : 0.44mm
    Weight (Head) 18.4 kg
    Packed Weight 23.6Kg
    Monitor Dimensions (W × H × D) 1,210.51 x 681.22 x 86.5mm
    Carton Dimensions (W × H × D) 1,353 x 855 x 263mm (Box outer size)
    Handle Yes
    VESA™ Standard Mount Interface 600 x 400
  • Environment Conditions

    Operation Temperature 0 °C to 40 °C
    Operation Humidity 10 % to 80 %
  • Power

    Power Supply AC 100-240V~, 50/60Hz
    Power Type Built-In Power
  • Power Consumption

    Typ./Max. 160 W / 190 W
    Smart Energy Saving 90W
    DPM 0.5 W
    Power off 0.5 W
    BTU (British Thermal Unit) 546 BTU/Hr(Typ.), 648 BTU/Hr(Max)
  • Standard (Certification)

    Safety CB / NRTL
    EMC FCC Class “B” / CE / KC
    ErP Yes (EU Only)
  • Software Compatibility

    SuperSign CMS Yes
    SuperSign Control / Control+ Yes
    SuperSign WB Yes
    SuperSign Media Editor Yes
    LG ConnectedCare Yes
  • Connectivity

    Input HDMI (2, HDCP2.2), DP (HDCP2.2), DVI-D (HDCP1.4), Audio, USB2.0 Type A(1)
    Output DP (Input : HDMI / DVI / DP), Audio
    External Control RS232C In/Out, RJ45 In/Out, IR In
  • Accessory

    Basic Remote Controller(include battery 2ea), Power Cord, RS232C cable, Lan calbe, DP cable, IR Receiver, Guide Bracket, Screws, Manual
    Optional OPS Kit(KT-OPSF)
