Key Feature

Brightness(Typ.) : 700 cd/m²
Bezel : 0.44 mm (Even)
Depth : 86.5 mm
Interface : HDMI(2)/ DP/ DVI-D/ RGB/ USB 2.0/ RS232C/ RJ45/ Audio/ IR

Download Brochure

Screen Size 55″
Panel Technology IPS
Aspect Ratio 16 : 9
Native Resolution 1920 x 1080 (FHD)
Brightness 700 cd/m2
Contrast Ratio 1,200:1
Viewing Angle (H x V) 178 x 178
Response Time 8ms (G to G)
Surface Treatment Haze 3%
Life Time (Typ.) 60,000 Hours
Operation Hours 24 Hours
Orientation Portrait & Landscape
Input HDMI (2), DP, DVI-D, RGB, Audio, USB 2.0
Output DP, Audio
External Control RS232C In/out, RJ45 In/out, IR In
Physical Specification
Bezel Color Black
Bezel Width 0.44 mm (Even)
Monitor Dimension (W x H x D) 1,210.51 x 681.22 x 86.5 mm
Weight (Head) 37.1 lbs / 16.8 kg
Carton Dimensions (W x H x D) 1,353.0 x 855.0 x 263.0 mm
Packed Weight 52.1 lbs / 23.6 kg
Handle Yes
VESA Standard Mount Interface 600mm x 400mm
Special Features
Special Features Internal Memory 8GB (System 4GB, Available 4GB), Temperature Sensor, Tile Mode (Up to 15×15), Natural Mode @Tile Mode, ISM Method, DPM Select, Smart Energy Saving, Contents Scheduling(USB, Internal Memory), USB Cloning, Easy Brightness Control, Calibration Mode, Content Rotation, OSD Portrait Mode, Sync Mode, PM Mode, Still Image Diagnosis, HDMI-CEC, Wake on LAN, Fail Over, No Signal Image (Up to 5MB), Embedded Template, Check Screen (via Pixel Sensor), OPS Power Control, Scan Inversion (with Pivot Mode)
Environmental Conditions
Operating Temperature Range 32 °F to 104 °F / 0°C to 40°C
Operating Humidity Range 10 % to 80 %
Power Supply 100-240V~, 50/60Hz
Power Type Built-In Power
Power Consumption – Typ. 170 W
Power Consumption – Max. 220 W
Standard (Certification)
Safety IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC FCC Class “A” / CE / KC
ErP / Energy Star N/A / Yes (Energy Star 7.0)
Media Player Compatibility
OPS Type Compatible Yes (Piggyback)
External Media Player Attachable Yes (MP500/MP700)
Software Compatibility
Content Management Software SuperSign CMS
Control and Monitoring Software SuperSign Control / Control+
Basic Remote Controller, Power Cord, RS232C Cable, LAN Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual
Optional Wall Mount (Landscape: WM-L640V, Portrait: WM-P640V), OPS Kit (KT-OPSA)
Warranty 3-Year Limited Warranty (Parts and Labor)
